用 SVG stroke-dasharray 完成倒數計時器
2020-06-11
Datavisualization
4 MIN

stroke-width

SVG 的 stroke 是一個很基本的屬性,如果在線段上,那他就是指整條線,例如 <path> <line> ,如果在圖形上那麼指的就是圖形的邊 <rect> <circle>,stroke 可以指定顏色,storke-width 可以指定寬度,那麼 storke-dasharray 可以幹嘛呢?它是用來畫 "虛線" 的。

讓我們來看看 MDN 的範例:

<svg viewBox="0 0 30 10" xmlns="http://www.w3.org/2000/svg">
  <!-- No dashes nor gaps -->
  <line x1="0" y1="1" x2="30" y2="1" stroke="black" />

  <!-- Dashes and gaps of the same size -->
  <line x1="0" y1="3" x2="30" y2="3" stroke="black"
          stroke-dasharray="4" />

  <!-- Dashes and gaps of different sizes -->
  <line x1="0" y1="5" x2="30" y2="5" stroke="black"
          stroke-dasharray="4 1" />

  <!-- Dashes and gaps of various sizes with an odd number of values -->
  <line x1="0" y1="7" x2="30" y2="7" stroke="black"
          stroke-dasharray="4 1 2" />

  <!-- Dashes and gaps of various sizes with an even number of values -->
  <line x1="0" y1="9" x2="30" y2="9" stroke="black"
          stroke-dasharray="4 1 2 3" />
</svg>

![mdn-example] (./images/entry7-1.png)

第一個 <line>,毫無反應就是條直的黑線

第二個 <line>,設置了storke-dasharray="4" 成為了一條黑白相間 4px 的虛線,(因為 storke-dasharray 如果輸入奇數的數組,會自動複製一份成為雙數),所以這條線其實是 stroke-dasharray="4 4" 4px 黑線 4px 白線。

第三條 <line>,設置了storke-dasharray="4 1",所以是 4px 黑線 1px 白線。

第四條 <line>,設置了```storke-dasharray="4 1 2"``,所以是 4, 1, 2, 4, 1, 2 循環的虛線

第五條 <line>,設置了```storke-dasharray="4 1 2 3"``,所以是 4px 黑線 1px 白線 2px 黑線 3px 白線的循環。

如何做動畫?

因為 stroke-dasharray 是 css 屬性,且支援 transition ,所以只要用 animation storke-dasharray 的值就可以辦到。

html:

<svg width="340px" height="333px" viewBox="0 0 340 333">
  <path class="path" fill="#FFFFFF" stroke="#000000" stroke-width="4" stroke-miterlimit="10" d="M66.039,133.545c0,0-21-57,18-67s49-4,65,8
    s30,41,53,27s66,4,58,32s-5,44,18,57s22,46,0,45s-54-40-68-16s-40,88-83,48s11-61-11-80s-79-7-70-41
    C46.039,146.545,53.039,128.545,66.039,133.545z"/>
</svg>

css:

.path {
  stroke-dasharray: 0 1000;
  animation: dash 5s linear infinite;
}

@keyframes dash {
  from {
    stroke-dasharray: 0 1000;
  }
  to {
    stroke-dasharray: 1000 1000;
  }
}

這是一個 path 長度為 1000 的不規則 svg path,初始設定了 stroke-dasharray: 0 1000,然後設定了一個五秒動畫會從 0 1000 到 1000 1000,就能呈現如下的效果:

![stroke-example] (./images/entry7-2.gif)

codepen在此

計時器

簡單的線條玩完了,那麼來點複雜的,標題所說的倒數計時器呢?

![timer] (./images/entry7-3.png)

期望的計時器長這樣,我用的方法是在 svg 裡面放了 2 個<circle>,一個當底另一個則拿來調整storke-dasharray,並用一個<text>來放剩餘時間,

<svg width="300" height="300">
  <circle cx="150" cy="150" r="50" />
  <circle id="circle" cx="150" cy="150" r="50" />
  <text id="text" x="150" y="149" />
</svg>
const total = 60;
const totalLength = 313.6517639160156;
let time = 0;

function draw() {
  const circle = document.getElementById('circle')
  circle.style.strokeDasharray = `${time / total * totalLength} 313.6517639160156`
  const text = document.getElementById('text')
  text.innerHTML = `${total - time}`
  time++
  time = time % 60
}

draw()

setInterval(() => {
  draw()
}, 1000)

接著每秒計算目前的時間剩餘比例,並換算出應該要設定的strokeDasharray值,在寫回<circle>上面,如此一來一個純 svg 會倒數的計時器就完成啦。

範例網址
